GOGO Normally Closed 2 Way Brass Gas Mini Solenoid Valve 1/8 1/4 M12 1.5mm/2.5mm/3mm Pneumatic welding machine burner valve

GOGO Normally Closed 2 Way Brass Gas Mini Solenoid Valve 1/8 1/4 M12 1.5mm/2.5mm/3mm Pneumatic welding machine burner valve

List Price: US $6.55
Price: US $4.98
You save: US $1.57 (24%)
Specification:
1/8"
1/4"
M12 Male
Voltage:
DC12V
DC24V
Wiring Control:
Orifice 1.5mm
Orifice 2.5mm
Orifice 3mm
Thread Type:
NBR Seal
FKM Seal
List Price: US $6.55
Price: US $4.98
You save: US $1.57 (24%)
item specifics
Brand Name:
ATC GOGO AUTOMATIC
Structure:
Control
Standard or Nonstandard:
Standard
Port Size:
G1/8",G1/4",M12
Power:
Solenoid
Media:
GAS
Material:
Brass
Pressure:
Medium Pressure
Model Number:
GMR
Temperature of Media:
Medium Temperature
NC or NO:
Normally Closed
Principium:
direct acting
For:
Air ,water ,liquid ,oil ,gas
Operating Temperature:
-5-80°C
Orifice:
1.5mm/2.5mm/3mm
type:
Normally colsed
Thread:
Female/male
Working pressure:
0-10/7/5bar
Voltage:
AC110V AC220V 24V DC 12V DC
Sealing materials:
NBR
Packing:
one piece valve + a carton
Product description

GOGO Normally Closed 2 Way Brass Gas Mini Solenoid Valve

NBR FKM Seals Pneumatic welding machine, burner valve

MR-M02 orifice: 1.5mm ,Pressure: 0-10bar ,G1/8″

MR-M03 orifce: 2.5mm ,Pressure:0-7bar, G1/8″ or G1/4″ ;

MR-03 Orifice: 3mm, Pressure: 0-4bar , thread: M12 male .

*Select China Post Air Mail Please note*
China Post Air Mail exists the problem of high risk of packet loss and Long time ,
we suggest that you use express transportation(EMS/DHL/Fedex/TNT/UPS) for safe and fast .

* * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * **

Voltage: 110V AC ,220V AC ,12V DC ,24V DC .

GMR Series Small Direct Slenoid valve

Model Pipe Orifice
Diameter(mm)
Principium CV Body
material
Seal Work Pressure
GMR-M02 1/8″ 1.5 direct acting 0.08 Brass NBR 0-10bar
GMR-M03 1/8″ 1/4″ 2.5 0.23 NBR 0-7bar
GMR-03 M12*1.25 3 0.3 NBR 0-4bar

1.Specification

Pattern: Two-port two-position
Principium: direct acting type
Control mode: normally close
Valve body: brass
Diaphragm material: NBR: ≤80°C ,FKM≤150°C
Voltage: AC220V AC110V DC12V DC24V
Medium: Air ,water ,Liquid ,oil ect.
Application: Gas protection welder, various types of burners, test equipment small-flow air water control system
2.Dimensions
3 .Picture

4.Packing

one pieces valve + a carton
